Benchmarking can sound simple: run a code and measure how long it takes. However, a lot of nuance is hidden here. It can be very easy to report benchmarking results which are unreliable or sell a particular narrative. We want our benchmarking to run like clean, reproducible experiments wherever possible.

In this blog we run through some basic steps to get started with running benchmarks, treating them as numerical experiments. We also signpost some resources and concepts to consider in future benchmarking.

Getting started

To begin benchmarking the main decisions are: choosing the software to run along with the hardware to benchmark. Then we document in detail the steps needed to get the benchmark built and running. This is particularly important as there are many variables in these steps which can impact performance.

Documentation is key! We recommend just a simple Markdown file, such as our pre-assessment template hosted here which can be modified to suit the analyst’s needs.

1. The code

To get started, we need a benchmark. If you are working on a code that does not currently ship with any benchmarks, SHAREing has written up some basic guidelines on how to write a representative benchmark which we link here.

We can often categorise most benchmarks as either synthetic or application benchmarks. Synthetic benchmarks are typically designed to stress a component of the hardware. One of the most famous is the STREAM benchmark which implements a handful of small compute kernels that do simple operations such as copying the elements of one array to another. These kernels are so computationally light that the only major bottleneck is memory bandwidth, i.e., the rate of reading and writing data from and to main memory. Hence, STREAM is used as a way of measuring the typical memory bandwidth of a CPU or GPU.

We also have application benchmarks which are typically small examples of a much bigger application software. For example, QMCPACK is a large quantum Monte Carlo code used in domains such as material science. The QMCPACK developers also produce miniQMC which is a smaller application that implements some of the computational kernels of QMCPACK but with a much shorter runtime. So we can use miniQMC as a representative benchmark of the larger performance of QMCPACK.

Having a suite of benchmarks for a performance-critical code, as is common in scientific computing, is a really useful way to check for any performance hits introduced during software development.

Finally, once we have chosen our code and benchmarks, it is best to use an archived version of the code, e.g., using a tagged branch of the code. Otherwise, if we clone the code that lives on the main branch of the repository, the code may change during our benchmarking.

2. Hardware

Hardware is a vital part of benchmarking. When beginning, pick hardware that you are interested in. This might be a system that you often use, or you might have in mind a hardware comparison. For example, you may be using a local institutional cluster but have in mind using a regional or national cluster. Hardware details can often be found in cluster documentation, so make a note of what you plan to use. If you are interested in trying hardware that you currently do not have access to, look into whether this is available through testbeds. For more information on available testbeds, please see the testbeds portal on the SHAREing webpages here.

This can be a deep rabbit hole, but to begin with we just note down the hardware that we are running on. The easiest option is to just copy what is listed on the documentation. For more information we can use tools such as

likwid-topology

and MAQAO, or system files such as

less /proc/cpuinfo

on Linux systems. However, these outputs are typically very detailed and go far beyond the data often used in simple hardware comparisons for benchmarking. Some example values, given by likwid-topology are core counts, cache sizes and NUMA domains. We might want to come back to these hardware details later when we can consider more in-depth benchmarking, but for now just noting the hardware name - e.g., Nvidia Grace-Hopper (GH200) - is sufficient.

3. Software dependencies

As with hardware, a code’s dependencies can impact performance, and so as above we recommend documenting. We want our benchmarking to be as reproducible as possible, so we document on a specific system any specific software. For example, note down compilers, libraries and version numbers.

On a cluster we can list our loaded software dependencies using

module list

and note down the output. An alternative and more granular method for noting the hardware and software environment of your benchmarking work is to use the MachineState tool, though we do not go into detail on this tool here.

4. Build

To begin our first benchmarking run, we almost want to not think. We just simply follow and document the build steps. This should include typical compiler flags used in the production code. Build steps are a classic example of a step in which the configuration can change code performance, so we just simply note down what we begin with. Then, once we have begun to collate results, we can see about whether there are different compilation options we can use.

5. Run

For a first run, we recommend running naively; do not worry too much how you are configuring the job, we just want an indicative run of the code. We can play around with parallel resources, etc. in the future, but to begin with we just pick a certain setup and run. This is to verify that the code runs, and check some basic resource usage such as total runtime and memory footprint.

On a SLURM-based system we can use

sacct -j <job-number> --format=elapsed,maxRSS

to give the total runtime (elapsed) and the memory footprint (maxRSS), once the code has completed.

Alternatively, we can time an application using /usr/bin/time which is a standardised tool on Linux (it is recommended to avoid just using time as this is not standardised across distributions of Linux), and then reading off the real time from this output. Then for total memory usage, on most Linux systems we have access to the valgrind tool which is used in detecting memory leaks, etc. Total memory usage can be found by

valgrind --tool=massif ./code

We note these results for future reference, but we now have some representative results for how our code performs. We can use this data in different ways to inform further benchmarking analyses:

1. Tweak resource allocations - we can compare how we configure our job scripts or allocate our parallel resources
2. Hardware comparisons - we can repeat our measurements across different hardware platforms to investigate performance changes and see whether certain hardware suits our code better
3. Software engineering and optimisation - if we change something in the code, do we know how this changes the performance of the code?
4. Varying dependencies - we can compare how different libraries or compilers may impact performance. For example, we may use some mathematical libraries when other vendor-optimised libraries available, so we can do some comparative benchmarking
5. And much more! There are so many variables in software development when it comes to performance, but starting to benchmark allows you to understand your code and the system more intimately.

We will touch on some of these ideas below.

Further things to consider

Now that we have documented our hardware, software and basic workflows for building and running the benchmark, we can then consider what other controls we have at our disposal.

6. Affinity and placement

As we have discussed, restricting any variables that we have control over is always desirable when benchmarking. For parallel applications we have the common issue of affinity: OpenMP threads and MPI ranks can change the physical core that they are assigned to which can then create performance inefficiencies as data then needs to be moved through the cache hierarchy and memory from near the previous core to the new core. Where possible we want to restrict this core switching by pinning our threads and have as near to 100% affinity as possible.

Often when wanting to increase affinity, we can also make the decision of which cores our threads and/or ranks are to. For parallel applications this can mean we have choices about where threads, ranks, etc. are placed. For example, where do we assign ranks for a GPU-aware MPI application? Convention dictates one rank per GPU, but what about if we have an OpenMP+MPI application: do we place a rank per NUMA domain? Or socket? Or node? There is no obvious answer to these questions, but benchmarking allows us to analyse these options. We can design our experiments to look into different methods of placing our processors.

One example of the impact placement can have is that for some compute-bound codes, close processor placement can be beneficial. Yet, for a code that is memory-bound it can be useful to place cores across different NUMA domains so they can exploit greater memory bandwidth across different memory regions. However, if memory needs to frequently be accessed across NUMA domains this creates performance issues.

So how do we fix affinity and choose our placement? Well for threads in an OpenMP application we can set environment variables OMP_PLACES to specify thread locations and OMP_PROC_BIND to specify how our threads are bound to these locations. This is easier to see in practice.

export OMP_PLACES=core
export OMP_PROC_BIND=close

will bind threads to physical cores, and will ensure that these are cores are close to one another, i.e., typically filling them out in logical order. So for a four thread application this will likely bind to cores labelled 0-3.

With MPI this can often be trickier as it can depend on the implementation of MPI or how the system is configured, and so it can vary system to system. So whilst we can handle our OpenMP thread affinity with environment variables, MPI can be difficult. Hence, we recommend the LIKWID tool suite which gives us an easy-to-use interface to select cores to pin too. For example, to pin to the first four cores we can use

likwid-pin -c 0-3 ./code

and LIKWID also gives us more explicit notation to state the cores by domains, e.g., 16 cores on a node in logical order could be

likwid-pin -c N:0-15 ./code

or if we have a dual-socket node, it could be 16 cores split across two sockets

likwid-pin -c S0:0-7@S1:8-15

Therefore, we can be very specific in our placement with this syntax. To understand the locations of these cores, please see the output of likwid-topology which will explain all of the available domains and their related cores.

For an MPI or hybrid parallel application we can also use

likwid-mpirun -np 4 ./code

and as with likwid-pin we can be specific in the physical cores we wish to pin our ranks and threads to but we recommend referring to the LIKWID Wiki for further details. Once more, we simply signpost LIKWID here as a tool that is incredibly useful in performance-oriented software development.

7. Scaling

A common aspect of benchmarking is scaling, i.e., exploring how runtime and other metrics vary with core count. We briefly look over the two dominant forms of scaling: strong and weak. For more information on the theory behind strong and weak scaling, please see our related videos on the High-Performance Computing Concepts knowledge graph.

Strong scaling

Put simply, strong scaling is increasing core count for fixed problem size. In an ideal case, doubling the core count should half the runtime. In reality this is never true for many reasons, not least because applications tend to have a serial portion which will retain fixed for increasing core counters.

A simple way of producing a strong scaling analysis for an MPI application is

for i in {1..128}
do
  /usr/bin/time mpirun -n $i ./code
done

By default this will print timing data to standard output, so we can pipe this data simply into a *.csv file and generate runtime plots. Often though, simply reporting the runtime as a function of core count is not the most useful data. It can be useful to calculate the speedup relative to the single core run, S(p) = t(1)/t(p), and parallel efficiency, E(p) = S(p)/p.

Thus, using these two metrics we can understand the core counts at which the code inefficiently uses the available parallelism. We can therefore use this to: tailor our job scripts to request a core count which efficiently uses the cores, without requesting too many; or, if the inefficiency is a significant issue then we can use this as a starting point for more in-depth performance analysis.

Weak scaling

In short, weak scaling is increasing core count with increasing problem size, so the work per core stays (in theory) approximately constant.

We can automate this as for strong scaling by iteratively allocating more and more cores, however, we need to equally scale up the problem size. This could be something like the following

for i in {1 2 4 8}
do
  /usr/bin/time mpirun -n $i ./code --input file_$i.dat
done

in which we are doubling the core count each at iteration, and are supplying an input file which doubles the problem size. In an ideal case with total parallel coverage, the runtime will remain exactly constant for each core count. However, in reality it is useful to study the parallel efficiency, E(p) = t(1)/t(p).

There is a difficult with weak scaling: how does the problem scale? If the problem scales linearly then doubling a scaling parameter, e.g., the number of grid points for the problem is simple. However, many problems may scale, e.g., logarithmically and so greater care has to be taken in planning an effective weak scaling for these codes.

Scaling with LIKWID: we can also include likwid-pin in our workflows above to include pinning and placement in our scaling analyses.

8. Compiler optimisations

As mentioned above, build steps are an aspect of benchmarking that can have significant effects on performance. Some hardware may have advanced instruction sets that can be exploited via compiler flags, so we may be able to get performance gains, without editing the source code through, e.g., further vectorisation. However, we always need to be skeptical during optimisation so we again run our benchmark experiments.

There is vast documentation online for compilers and their flags, often with pages dedicated to optimisation flags. However, these documentation pages are typically not the easiest to navigate when starting out with compiler optimisations. MAQAO can suggest compiler flags that can exploit hardware features and so we recommend this as an easier place to start with identifying compiler optimisations.

One feature of MAQAO which can help here is its compare reports feature. We can create a simple workflow of running an individual benchmark for each compiler optimisation we may be exploring with MAQAO. Then, we can collect these different runs together to explore how the different compiler optimisations vary the runtime and more detailed performance features of the code. This can become a very detailed form of analysis, so we leave it to the reader to explore MAQAO in further detail.

9. Metrics

Above we have looked at several variables to explore in benchmarking, from affinity to placement to scaling. In all of this, our observable is total runtime which we can then use to look at speedup and efficiency in scaling analyses. However, there are other metrics we can use. For example, we might want to explore domain specific metrics. It can be really useful in defining a metric that is specific to an algorithm or code, e.g., in lattice-based methods, something like the ‘number of lattice site updates’ can be really useful for code specific performance metrics. Alternatively, we can repeat above methods but gather metrics from hardware counters using likwid-perfctr, then, paired with scaling analyses, we can measure how metrics such as memory bandwidth or compute rate scales.

For more information, please see the likwid-perfctr documentation on the LIKWID Wiki but here we will just higlight some key features to get started with.

To see which performance groups are available on the system of interest, we run

likwid-perfctr -a

and can then select a performance group of interest. Please note: performance groups are not universal. Different systems - i.e., vendors and chip generations - allow for different performance groups, so always check which are available on a given system. Once we select a performance group we can use the likwid-perfctr command, along with our pinning and placement notation. For the MEM performance group, which looks at traffic from main memory, we would use the following

likwid-perfctr -C 0-7 -g MEM ./code

which runs across the first 8 cores on our node. This will print out raw hardware counter data, but useful for the average user are the summarised metrics which we can use to study our code’s performance.

These metrics are captured globally across the whole application. If we want to target specific code blocks - e.g., if we have used a profiler and found a particular hotspot that we want to analyse - then we can use LIKWID’s marker API to collect metrics on the specific code blocks.

Finally, as we used likwid-pin to coordinate our affinity and placement, and then likwid-perfctr to extend this functionality to gather hardware performance counters, we can add the gathering of hardware performance counter data to likwid-mpirun for MPI and hybrid parallel jobs. We can do this by adding -g <PERFORMANCE_GROUP> to our likwid-mpirun call.

In summary, hardware performance counters can extend some of the benchmarking we have seen earlier to help us add more data to our benchmarking beyond total runtimes and speedups. However, this analysis can become quite detailed and so we do not recommend skipping right to this step. Instead, it is best to step-by-step work through earlier sections in documentation, experimentation with placement, affinity and scaling. We can then turn to hardware performance counters for more detailed analysis.

Supporting materials

We hope that this introduction to benchmarking is useless, and to support this we list below further materials to help in your future benchmarking!

SHAREing

This blog has given just an introduction to some benchmarking concepts and as part of SHAREing we are building a performance assessment of which benchmarking forms the basis. To get started in following SHAREing’s performance methodology, we have GitHub hosted templates for our pre-assessment and high-level assessment which covers much of the topics covered here. More detail can be found in the SHAREing performance assessment guidebook.

Reproducible and automated benchmarking

For automating benchmarking consider looking into Reframe and JUBE. This can help automate benchmarking workflows to aggregate together statistics. A paper by the ExCALIBUR project on automated and reproducible benchmarking practices can be found here. If benchmarking is to become a feature of your research outputs, then there is a useful paper on benchmarking best practice particularly in reporting results linked here.

HPC Wiki

Finally, a useful resource for many concepts in HPC is the HPC Wiki which presents useful overviews of concepts and workflows in both benchmarking and scaling analysis, linked here.
